Technical Details
Physical
Mount Surface Mount
Weight 6.350293g
Technical
Packaging Bulk
Published 2005
Pbfree Code yes
Part Status Active
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO
HTS Code 8504.31.40.35
Power Rating 4W
Physical Dimension L21.0XB16.5XH5.5 (mm)
Inductance 20 μH
Current - Output 10mA
Lead/Base Style Gull Wing
Voltage - Output 1.34kV
Operating Frequency-Max 80kHz
Operating Frequency-Min 40kHz
Transformer Type POWER TRANSFORMER
Primary Winding(s) Dual
Turns Ratio - Primary:Secondary 1:100
Secondary Winding(s) Single
VA Rating 4 VA
Center Tap Feature 1 NO
Center Tap Feature 2 NO
Dimensions
Height 5.5mm
Height Seated (Max) 5.5mm
Length 21mm
Width 16.5mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
