6025-024
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 12VA THRU HOLE
PDF
/
Inventory: 4516
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.7lb 317.51g
Technical
Packaging Bulk
Published 2010
Series 6025
Size / Dimension 47.63mm Lx39.67mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
Type Laminated Core
Power Rating 12W
Max Power Dissipation 12W
Termination Style PC Pin
Voltage - Isolation 2500Vrms
Max Output Current 1A
Current - Output (Max) Parallel 1A Series 500mA
Element Configuration Dual
Power - Max 12VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Secondary Winding(s) Dual
Dimensions
Height Seated (Max) 36.50mm
Length 47.63mm
Width 39.67mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
