AE101MD1CQ
RoHS
/
Package /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 5A 120V
PDF
/
Inventory: 6576
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Actuator Material Copper Alloy
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Published 2004
Series Gemini AE
Feature Process Sealed
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Standard Round
Circuit SPDT
Switch Function On-On
ELV Non-Compliant
Electrical Life 6,000 Cycles
Throw Configuration SPDT
Illumination Non-Illuminated
Illumination Type Non-Illuminated
Bushing Thread Unthreaded
Dimensions
Actuator Length 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
