M2033BB3W01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON OFF ON 3PDT Large Bat Lever Solder Lug 6A 250VAC 30VDC Panel Mount with Threads
PDF
/
Inventory: 7238
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 11.50mm
Length 18mm
Technical
Bushing Thread M12 x 1
Illumination Type Non-Illuminated
Max Voltage Rating (DC) 30V
Illumination Non-Illuminated
Throw Configuration 3PDT
Electrical Life 25,000 Cycles
Max Current Rating 6A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Circular - 12.50mm Dia
Switch Function On-Off-On
Circuit 3PDT
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 3A
Depth 18mm
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating (Amps) 6A AC 3A DC
Voltage - Rated DC 30V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series M
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount
Mount Panel
Contact Plating Silver
Contact Material Silver
