M2022LL3W01-C
RoHS
/
Package /
Category Switches / Toggle Switches
Description
Toggle Switches DPDT ON-NONE-ON LCKNG LVR CONICL CAP
PDF
/
Buying Options
Total Price: USD $7.07
Unit Price: USD $7.066961
≥1 USD $7.066961
≥10 USD $6.666943
≥100 USD $6.28957
≥500 USD $5.933561
≥1000 USD $5.597696
Inventory: 1140
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Silver
Mounting Type Panel Mount
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2014
Series M
Feature Red Cap
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Voltage - Rated DC 30V
Current Rating (Amps) 6A AC 4A DC
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 3A
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Locking Lever
Circuit DPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 6.50mm Dia
Electrical Life 25,000 Cycles
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Illumination Type Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 16.50mm
