M2015SS2A13
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 6A 125V
PDF
/
Inventory: 10041
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 10.50mm
Length 16.3mm
Technical
Bushing Thread Unthreaded
Switch Type TOGGLE SWITCH
Max Voltage Rating (DC) 30V
Illumination Non-Illuminated
Electrical Life 25,000 Cycles
Max Current Rating 6A
Max Voltage Rating (AC) 250V
Switch Function On-Mom
Circuit SPDT
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 3A
Depth 8mm
Current Rating (Amps) 6A AC 3A DC
Voltage - Rated DC 30V
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series M
Packaging Tray
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Silver
