M2013B2B1A06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Toggle Switches ON-OFF-ON .689 LRG BAT 12MMBUSH WR WRAP
PDF
/
Inventory: 9537
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 17.50mm
Technical
Bushing Thread M12 x 1
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 25,000 Cycles
Panel Cutout Dimensions Circular - 12.50mm Dia
Switch Function On-Off-On
Circuit SPDT
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Wire Wrap
Current Rating 3A
Current Rating (Amps) 6A AC 3A DC
Voltage - Rated DC 30V
Power Rating 400mW
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
Series M
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold, Silver
Supply Chain
Factory Lead Time 10 Weeks
