AML23EBA2DA06
RoHS
/
Package /
Category Switches / Toggle Switches
Description
Paddle AML23 3 Panel Mount Snap-In Toggle Switch 28.85mm 0.1A 125V .1A@125VAC
PDF
/
Inventory: 8642
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Contact (DC) Max Rating R Load .1A@125VDC
Contact (AC) Max Rating R Load .1A@125VAC
Contact Current(AC)-Max 0.1A
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 25,000 Cycles
Contact Current(DC)-Max 0.1A
Panel Cutout Dimensions Rectangular - 28.98mm x 19.05mm
Switch Function On-On-Mom
Circuit DPDT
Actuator Type Paddle
Body Breadth 18.92 mm
Body Length or Diameter 28.85mm
Voltage - Rated AC 125V
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Current Rating 100mA
Reach Compliance Code unknown
Orientation Straight
Current Rating (Amps) 100mA AC/DC
Voltage - Rated DC 125V
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series AML23
Published 2001
Packaging Bulk
Physical
Number of Pins 3
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Material Gold
Supply Chain
Factory Lead Time 18 Weeks
