Category Switches / Toggle Switches
Description
Switch Toggle ON OFF ON SPDT Round Lever Quick Conn 20A 277VAC 250VDC Panel Mount with Threads
PDF
/
Buying Options
Total Price: USD $32.59
Unit Price: USD $32.5864
≥1 USD $32.5864
Inventory: 81
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Material Cadmium, Silver
Contact Plating Gold
Mount Bushing
Mounting Type Panel Mount
Number of Pins 3
Technical
Operating Temperature -40°C~71°C
Packaging Bulk
Published 2001
Series NT
Feature Sealed
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Voltage - Rated DC 250V
Current Rating (Amps) 15A AC
Orientation Straight
Ingress Protection IP67/68 - Dust Tight, Waterproof
Depth 15.7mm
Reach Compliance Code unknown
Current Rating 15A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Actuator Type Standard Round
Circuit SPDT
Switch Function On-Off-On
Panel Cutout Dimensions Circular - 12.40mm Dia
Sealing IP67; IP68
Max Voltage Rating (AC) 277V
Max Current Rating 20A
Illumination Non-Illuminated
Max Voltage Rating (DC) 250V
Switch Type TOGGLE SWITCH
Bushing Thread 15/32-32
Contact (AC) Max Rating R Load 15A@115VAC
Contact (DC) Max Rating R Load 20A@28VDC
Dimensions
Length 28.6mm
Body Height 29.5mm
Actuator Length 17.02mm
Compliance
RoHS Status RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
