100SP5T1B6M1REH

E-Switch
RoHS
RoHS RoHS compliant
Package /
Category Switches / Toggle Switches
Description Toggle Switches 0.4VA @ 20V (AC/DC) On-Off-(On) Sldr Lug
PDF
/
Buying Options
Total Price: USD $6.44
Unit Price: USD $6.435836
≥1 USD $6.435836
≥192 USD $2.568032
≥480 USD $2.482694
≥960 USD $2.440681
Inventory: 6660
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mounting Type Panel Mount
Surface Mount NO
Insulation Material DIALLYL PHTHALATE
Housing Material STAINLESS STEEL
Actuator Material Brass, Chrome Plated
Center Contact Plating GOLD
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY

Technical

Operating Temperature -30°C~85°C
Packaging Tray
Published 2008
Series 100
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Current Rating (Amps) 0.4VA AC/DC
Termination Style Solder Lug
Voltage - Rated AC 20V
Body Length or Diameter 12.7mm
Body Breadth 6.858 mm
Actuator Type Standard Round
Circuit SPDT
Switch Function On-Off-Mom
Panel Cutout Dimensions Circular - 6.35mm Dia
Contact Resistance 0.01mOhm
Electrical Life 40,000 Cycles
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread 1/4-40
Contact Function ON-OFF-(ON)
Bushing Length 0.315 inch

Dimensions

Body Height 10.414mm
Length - Termination 0.156 inch
Actuator Length 9.90mm

Compliance

RoHS Status ROHS3 Compliant
