100SP1T1B2M71QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Toggle Switches 5A 120VAC/28VDC On-None-On PC Mnt
PDF
/
Inventory: 9684
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole, Right Angle, Vertical
Insulation Material DIALLYL PHTHALATE
Housing Material STAINLESS STEEL
Actuator Material Brass, Chrome Plated
Center Contact Plating SILVER
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2008
Series 100
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Termination Style PC Pin
Voltage - Rated AC 120V
Body Length or Diameter 6.858mm
Body Breadth 12.7 mm
Actuator Type Standard Round
Circuit SPDT
Switch Function On-On
Contact Resistance 0.01mOhm
Contact Current(DC)-Max 5A
Contact Voltage(DC)-Max 28V
Electrical Life 40,000 Cycles
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread Unthreaded
Contact Current(AC)-Max 2A
Contact (AC) Max Rating R Load 2A@250VAC
Contact Voltage(AC)-Max 250V
PCB Hole Count 5
Bushing Length 0.331 inch
Dimensions
Length - Termination 0.125 inch
Actuator Length 10.41mm
Compliance
RoHS Status ROHS3 Compliant
