100DP1T1B1M7QEH
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 5A 120V
PDF
/
Buying Options
Total Price: USD $4.34
Unit Price: USD $4.3384
≥1 USD $4.3384
≥10 USD $3.87288
≥100 USD $3.667136
≥500 USD $3.535998
≥1000 USD $3.367663
≥3000 USD $3.218002
Inventory: 578
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 10.41mm
Length - Termination 0.125 inch
Body Height 20.32mm
Technical
Bushing Length 0.331 inch
PCB Hole Count 8
Contact Voltage(AC)-Max 120V
Contact Current(AC)-Max 5A
Bushing Thread 1/4-40
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 40,000 Cycles
Contact Voltage(DC)-Max 28V
Contact Current(DC)-Max 5A
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Standard Round
Body Breadth 12.7 mm
Body Length or Diameter 11.43mm
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 100
Published 2014
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Center Contact Plating SILVER
Actuator Material Brass, Chrome Plated
Housing Material STAINLESS STEEL
Insulation Material DIALLYL PHTHALATE
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Surface Mount NO
Mounting Type Panel Mount, Right Angle, Vertical
Supply Chain
Factory Lead Time 7 Weeks
