U215SY9AQE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle Mom ON Mom DPDT Round Lever PC Pins 5A 250VAC 28VDC PC Mount with Bracket
PDF
/
Inventory: 1563
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Silver
Mount Brackets, Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Series 7000
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Depth 36.71mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Standard Round
Circuit SP3T
Switch Function Mom-On-Mom
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 40,000 Cycles
Throw Configuration DPDT, SP3T
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Non-Illuminated
Bushing Thread Unthreaded
Dimensions
Length 12.7mm
Actuator Length 10.67mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
