M83731/15-231
RoHS
/
Package /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 5A 115V
PDF
/
Buying Options
Total Price: USD $32.7
Unit Price: USD $32.701004
≥1 USD $32.701004
≥10 USD $30.850008
≥100 USD $29.103777
≥500 USD $27.456393
≥1000 USD $25.902255
Inventory: 1183
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Material Brass, Gold, Silver
Contact Plating Gold
Mount Brackets
Mounting Type Through Hole, Right Angle
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -25°C~71°C
Packaging Tray
Published 2012
Series M83731
Feature Epoxy Sealed Terminals
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Current Rating (Amps) 5A AC/DC
Orientation Right Angle
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 115V
Actuator Type Standard Round
Circuit SPDT
Switch Function On-On
Max Voltage Rating (AC) 125V
Max Current Rating 5A
Electrical Life 10,000 Cycles
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Mechanical Life 20000 cycles
Bushing Thread Unthreaded
Dimensions
Length 12.95mm
Actuator Length 6.90mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
