7401MDAV2BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE 4PDT 0.4VA 20V
PDF
/
Inventory: 6931
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Mount Brackets, Panel, Vertical
Mounting Type Panel Mount, Right Angle, Vertical
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Standard Round
Circuit 4PDT
Switch Function On-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration 4P, 4PDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 6.86mm
Compliance
RoHS Status ROHS3 Compliant
