ET01M3D1SAPE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $4.85
Unit Price: USD $4.8488
≥1 USD $4.8488
Inventory: 406
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Plating Gold
Mount Brackets, Surface Mount
Mounting Type Surface Mount, Right Angle
Actuator Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature -30°C~85°C
Packaging Tape & Reel (TR)
Published 2010
Series ET
Feature Black Antistatic Actuator
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Right Angle
Ingress Protection IP57 - Dust Protected, Waterproof
Termination Style Gull Wing
Voltage - Rated AC 20V
Actuator Type Standard Round
Circuit SPDT
Switch Function On-On
Max Voltage Rating (AC) 20V
Electrical Life 60,000 Cycles
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Bushing Thread Unthreaded
Dimensions
Length 10.41mm
Actuator Length 6.10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings IP57, Waterproof
