7215K9V61QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SP3T 5A 120V
PDF
/
Inventory: 1977
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Silver
Mount Brackets, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Aluminum
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Orientation Straight
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Locking Lever
Circuit SP3T
Switch Function Mom-On-Mom
Max Voltage Rating (AC) 250V
Electrical Life 40,000 Cycles
Throw Configuration DP, DPDT, SP3T
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread Unthreaded
Dimensions
Actuator Length 17.88mm
Compliance
RoHS Status ROHS3 Compliant
