7213SDAW5QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SP3T 5A 120V
PDF
/
Buying Options
Total Price: USD $23.71
Unit Price: USD $23.714913
≥1 USD $23.714913
Inventory: 1312
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 12.45mm
Technical
Bushing Thread 1/4-40
Illumination Type Illuminated, Non-Illuminated
Illumination Non-Illuminated
Throw Configuration DP, DPDT, SP3T
Electrical Life 40,000 Cycles
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On-Mom
Circuit SP3T
Actuator Type Standard Round
Voltage - Rated AC 120V
Termination Style Wire Wrap
Current Rating 5A
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Jumper needed to achieve triple throw
Series 7000
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount, Right Angle
Mount Brackets, Panel
Contact Plating Silver
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
