7211P3YZGE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SP3T 5A 120V
PDF
/
Buying Options
Total Price: USD $29.73
Unit Price: USD $29.734559
≥1 USD $29.734559
Inventory: 1176
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Gold
Mount Panel
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Orientation Straight
Current Rating 5A
Termination Style Solder Lug
Voltage - Rated AC 120V
Actuator Type Flat Anti-Rotation
Circuit SP3T
Switch Function On-On-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 250V
Electrical Life 40,000 Cycles
Throw Configuration DP, DPDT, SP3T
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 11.43mm
Compliance
RoHS Status ROHS3 Compliant
