7201SYAV2BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round 7000 Panel Mount Right Angle Vertical Bulk Toggle Switch 10.67mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Buying Options
Total Price: USD $11.17
Unit Price: USD $11.167527
≥1 USD $11.167527
≥200 USD $4.322067
≥500 USD $4.16977
≥1000 USD $4.094935
Inventory: 2270
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length 10.67mm
Technical
Bushing Thread 1/4-40
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Throw Configuration DP, DPDT
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Standard Round
Voltage - Rated AC 20V
Termination Style PC Pin
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Panel Mount, Right Angle, Vertical
Mount Brackets, Panel, Vertical
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
