7107TCWCBE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $10.38
Unit Price: USD $10.377965
≥1 USD $10.377965
≥10 USD $9.790526
≥100 USD $9.236354
≥500 USD $8.713541
≥1000 USD $8.220329
Inventory: 1441
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 17.45mm
Technical
Bushing Thread 15/32-32
Illumination Type Illuminated, Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Throw Configuration SP, SPDT
Electrical Life 40,000 Cycles
Max Voltage Rating (AC) 20V
Panel Cutout Dimensions Circular - 11.91mm Dia
Switch Function On-Off-Mom
Circuit SPDT
Actuator Type Standard Round
Voltage - Rated AC 20V
Termination Style PC Pin
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Panel Mount
Mount Panel
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
