7103TV3BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $11.74
Unit Price: USD $11.737784
≥1 USD $11.737784
≥10 USD $11.073387
≥100 USD $10.446587
≥500 USD $9.855278
≥1000 USD $9.297427
Inventory: 1583
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Gold
Mount Brackets, Panel
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Tray
Published 2011
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Straight
Depth 8.13mm
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Standard Round
Circuit SPDT
Switch Function On-Off-On
Panel Cutout Dimensions Circular - 11.91mm Dia
Max Voltage Rating (AC) 20V
Electrical Life 40,000 Cycles
Throw Configuration SP, SPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 15/32-32
Dimensions
Length 16.26mm
Actuator Length 17.45mm
Compliance
RoHS Status ROHS3 Compliant
