SX0793/63
RoHS
/
Package /
Category Switches / Toggle Switches
Description
Toggle Switch, On-On, SPDT, Non Illuminated, Panel, 10 A
PDF
/
Inventory: 3155
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper, Silver
Mount Panel
Mounting Type Panel Mount
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Published 2003
Series SX
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Voltage - Rated DC 28V
Current Rating (Amps) 10A AC/DC
Orientation Straight
Depth 15.1mm
Current Rating 10A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 250V
Actuator Type Standard Round
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 12.00mm Dia
Contact Resistance 10mOhm
Max Voltage Rating (AC) 250V
Max Current Rating 10A
Number of Poles 1
Throw Configuration SPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Contact Current Rating 10A
Illumination Type Illuminated
Dimensions
Height 37.5mm
Length 37.3mm
Width 15mm
Actuator Length 20.20mm
Width - Tab 6.3mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
