SW246CD7
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 0.4VA 20V
PDF
/
Inventory: 962
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Brass
Contact Plating Gold
Mount Brackets, Through Hole
Mounting Type Through Hole, Right Angle
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Series S
JESD-609 Code e4
Feature Sealed
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
HTS Code 8536.50.90.65
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Right Angle
Current Rating 2A
Termination Style PC Pin
Voltage - Rated AC 20V
Body Length or Diameter 12.7mm
Body Breadth 12.7 mm
Actuator Type Standard Round
Circuit DPDT
Switch Function On-On
Contact Resistance 10mOhm
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Bushing Thread Unthreaded
Contact (AC) Max Rating R Load .02A@20VAC
Contact (DC) Max Rating R Load .02A@20VDC
Dimensions
Body Height 11.65mm
Actuator Length 7.50mm
Compliance
RoHS Status ROHS3 Compliant
