5666AB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE 4PDT 6A 125V
PDF
/
Buying Options
Total Price: USD $16.44
Unit Price: USD $16.4384
≥1 USD $16.4384
≥10 USD $14.93184
≥100 USD $14.768864
Inventory: 63
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 10.50mm
Body Height 13.1mm
Technical
Contact (DC) Max Rating R Load 4A@30VDC
Contact (AC) Max Rating R Load 6A@125VAC
Contact Current(AC)-Max 6A
Bushing Thread 1/4-40
Switch Type TOGGLE SWITCH
Mechanical Life 100000 cycles
Max Voltage Rating (DC) 30V
Illumination Non-Illuminated
Electrical Life 30,000 Cycles
Max Voltage Rating (AC) 250V
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 4A
Contact Resistance 10mOhm
Panel Cutout Dimensions Circular - 6.50mm Dia
Switch Function On-On
Circuit 4PDT
Actuator Type Standard Round
Body Breadth 13.2 mm
Body Length or Diameter 21.2mm
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 4A
Orientation Straight
Current Rating (Amps) 6A AC 4A DC
Voltage - Rated DC 30V
HTS Code 8536.50.90.65
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e4
Series 5000
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Actuator Material Brass, Nickel Plated
Housing Material Stainless Steel
Mounting Type Panel Mount
Mount Panel
Contact Material Silver
Supply Chain
Factory Lead Time 9 Weeks
