5246ZABG21+U642
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 6A 125V
PDF
/
Inventory: 6760
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 21.30mm
Technical
Bushing Thread 1/4-40
Illumination Type Non-Illuminated
Illumination Non-Illuminated
Throw Configuration DPDT
Electrical Life 50,000 Cycles
Panel Cutout Dimensions Circular - 6.50mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.062 (1.5mm)
Current Rating 4A
Current Rating (Amps) 6A AC 4A DC
Voltage - Rated DC 30V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Matte Black Finish
Series 5000
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Brass, Nickel Plated
Mounting Type Panel Mount
Mount Panel
Supply Chain
Factory Lead Time 14 Weeks
