1531A8L12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPST 10A 125V
PDF
/
Inventory: 5880
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 15.00mm
Body Height 9.5mm
Technical
Contact (AC) Max Rating R Load 10A@125VAC
Contact Current(AC)-Max 10A
Bushing Thread M12 x 0.75
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 6000 Cycle(s)
Sealing DUST PROOF; WATER PROOF
Contact Current(DC)-Max 5A
Panel Cutout Dimensions Circular - 12.20mm Dia
Switch Function On-Off
Circuit SPST
Actuator Type Standard Round
Body Breadth 12 mm
Body Length or Diameter 18.8mm
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.187 (4.7mm)
Current Rating 5A
Current Rating (Amps) 10A AC 5A DC
Voltage - Rated DC 12V
HTS Code 8536.50.90.65
Terminal Finish Silver (Ag)
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 1500
Packaging Bulk
Operating Temperature -20°C~55°C
Physical
Actuator Material Polyamide (PA), Nylon
Mounting Type Panel Mount
Mount Panel
Supply Chain
Factory Lead Time 9 Weeks
