BTA16-800BRG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC 800V 16A TO220AB
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.1528
≥1 USD $1.1528
≥10 USD $0.9416
≥100 USD $0.923824
≥500 USD $0.732072
≥1000 USD $0.72505
≥3000 USD $0.620479
Inventory: 1025
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 4.535924g
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Additional Feature UL RECOGNIZED
Subcategory TRIACs
Voltage - Rated DC 800V
Current Rating 16A
Base Part Number BTA16
Pin Count 3
Number of Elements 1
Configuration Single
Case Connection ISOLATED
Max Repetitive Reverse Voltage (Vrrm) 800V
JEDEC-95 Code TO-220AB
RMS Current (Irms) 16A
Hold Current 50mA
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 160A 168A
Current - Gate Trigger (Igt) (Max) 50mA
Leakage Current (Max) 2mA
Critical Rate of Rise of Off-State Voltage-Min 400V/us
Triac Type Standard
Critical Rate of Rise of Commutation Voltage-Min 10V/us
Dimensions
Height 9.3mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
