LX807DE
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
Bulk Through Hole Logic - Sensitive Gate Single TRIAC 1.5V/us 5mA 1.3V -40C~110C TJ
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.409625
≥1 USD $0.409625
≥200 USD $0.164113
≥500 USD $0.158861
≥1000 USD $0.156235
Inventory: 1145
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Technical
Operating Temperature -40°C~110°C TJ
Packaging Bulk
Published 2008
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Additional Feature HIGH RELIABILITY
Subcategory TRIACs
Voltage - Rated DC 400V
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Current Rating 800mA
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Configuration Single
RMS Current (Irms) 800mA
Hold Current 5mA
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 8A 9.5A
Current - Gate Trigger (Igt) (Max) 5mA
Leakage Current (Max) 0.1mA
Critical Rate of Rise of Off-State Voltage-Min 10V/us
Triac Type Logic - Sensitive Gate
RMS On-state Current-Max 0.8A
Critical Rate of Rise of Commutation Voltage-Min 1.5V/us
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
