VS-2N5205
RoHS
RoHS compliant
RoHS compliantPackage TO-208AA, TO-48-3, Stud
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR PHASE CONT 800V 35A TO-48
PDF
/
Inventory: 8468
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Repetitive Peak Reverse Voltage 800V
Current - Off State (Max) 2.5mA
Voltage - On State (Vtm) (Max) 2.3V
SCR Type Standard Recovery
Current - On State (It (AV)) (Max) 22A
Repetitive Peak Off-state Voltage 800V
Current - On State (It (RMS)) (Max) 35A
Current - Gate Trigger (Igt) (Max) 40mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 285A 300A
Voltage - Gate Trigger (Vgt) (Max) 2V
Voltage - Off State 800V
Trigger Device Type SCR
Hold Current 200mA
RMS Current (Irms) 35A
Configuration SINGLE
Number of Elements 1
Pin Count 2
Base Part Number 2N52*
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form SOLDER LUG
Terminal Position UPPER
Additional Feature HIGH RELIABILITY
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 1997
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Number of Pins 2
Package / Case TO-208AA, TO-48-3, Stud
Mounting Type Chassis, Stud Mount
Mount Chassis, Stud
Supply Chain
Factory Lead Time 14 Weeks
