TYN640RG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 600V 40A TO-220AB
PDF
/
Buying Options
Total Price: USD $1.5
Unit Price: USD $1.5048
≥1 USD $1.5048
≥10 USD $1.20824
≥100 USD $0.994136
≥500 USD $0.841192
≥1000 USD $0.713742
≥3000 USD $0.678058
Inventory: 682
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.15mm
Technical
Current - Off State (Max) 5μA
Critical Rate of Rise of Off-State Voltage-Min 1000V/us
Voltage - On State (Vtm) (Max) 1.6V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 480 A
Current - On State (It (AV)) (Max) 25A
Leakage Current (Max) 4mA
Current - Gate Trigger (Igt) (Max) 35mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 460A 480A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Trigger Device Type SCR
Hold Current 75mA
RMS Current (Irms) 40A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 600V
Forward Voltage 1.6V
Configuration SINGLE
Number of Elements 1
Pin Count 3
Base Part Number TYN640
Current Rating 40A
Terminal Position SINGLE
Voltage - Rated DC 600V
Subcategory Silicon Controlled Rectifiers
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 2.299997g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
