TYN612MFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 600V 12A TO-220FPAB
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.639936
≥100 USD $0.507144
≥500 USD $0.429845
≥1000 USD $0.350152
≥3000 USD $0.32963
Inventory: 3882
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Current - Off State (Max) 10μA
Critical Rate of Rise of Off-State Voltage-Min 50V/us
Voltage - On State (Vtm) (Max) 1.6V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 125 A
Current - On State (It (AV)) (Max) 8A
Leakage Current (Max) 2mA
Current - Hold (Ih) (Max) 20mA
Current - Gate Trigger (Igt) (Max) 5mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 120A 125A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Trigger Device Type SCR
Hold Current 20mA
RMS Current (Irms) 12A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 600V
Case Connection ISOLATED
Configuration SINGLE
Number of Elements 1
Pin Count 3
Base Part Number TYN612
Current Rating 12A
Terminal Position SINGLE
Voltage - Rated DC 600V
Subcategory Silicon Controlled Rectifiers
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 9 Weeks
