ZMV832BTA
RoHS
/
Package SC-76, SOD-323
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
DIODE VAR CAP 22PF 25V SOD-323
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.1349
≥1 USD $0.1349
≥10 USD $0.1102
≥100 USD $0.10735
≥500 USD $0.10355
≥1000 USD $0.1007
Inventory: 6005
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-76, SOD-323
Number of Pins 2
Weight 4.904468mg
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Solder
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.80
Capacitance 23.1pF
Subcategory Varactors
Voltage - Rated DC 25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number ZMV832
Pin Count 2
Number of Elements 1
Power Dissipation-Max 0.33W
Diode Type Single
Forward Current 200mA
Capacitance @ Vr, F 23.1pF @ 2V 1MHz
Reverse Voltage (DC) 25V
Diode Capacitance-Nom 22pF
Capacitance Ratio 6.5
Capacitance Ratio Condition C2/C20
Diode Cap Tolerance 5%
Quality Factor-Min 200
Q @ Vr, F 200 @ 3V, 50MHz
Dimensions
Height 1.05mm
Length 1.8mm
Width 1.45mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
