TYN412RG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
Thyristor SCR 400V 125A 3-Pin(3+Tab) TO-220AB Tube
PDF
/
Buying Options
Total Price: USD $1
Unit Price: USD $1.0032
≥1 USD $1.0032
≥10 USD $0.803264
≥100 USD $0.636504
≥500 USD $0.539493
≥1000 USD $0.533614
Inventory: 1692
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 15.75mm
Technical
Circuit Commutated Turn-off Time-Nom 50 μs
Current - Off State (Max) 5μA
Critical Rate of Rise of Off-State Voltage-Min 50V/us
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 120 A
Current - On State (It (AV)) (Max) 8A
Current - On State (It (RMS)) (Max) 12A
Current - Hold (Ih) (Max) 30mA
Current - Gate Trigger (Igt) (Max) 15mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 140A 145A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Trigger Device Type SCR
Hold Current 30mA
RMS Current (Irms) 12A
Max Repetitive Reverse Voltage (Vrrm) 400V
Forward Voltage 1.6V
Number of Elements 1
Base Part Number TYN412
Current Rating 10A
Voltage - Rated DC 400V
Subcategory Silicon Controlled Rectifiers
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 2.299997g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 11 Weeks
