T727024554DN
RoHS
RoHS compliant
RoHS compliantPackage SC-20, Stud
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR FAST SW 450A 200V TO-220AC
PDF
/
Inventory: 7232
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Repetitive Peak Reverse Voltage 200V
Current - Off State (Max) 30mA
Critical Rate of Rise of Off-State Voltage-Min 300V/us
Voltage - On State (Vtm) (Max) 1.45V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 8000 A
Current - On State (It (AV)) (Max) 450A
Leakage Current (Max) 30mA
Repetitive Peak Off-state Voltage 200V
Current - Gate Trigger (Igt) (Max) 150mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 8000A @ 60Hz
Voltage - Gate Trigger (Vgt) (Max) 3V
Voltage - Off State 200V
Trigger Device Type SCR
RMS Current (Irms) 700A
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-XXDB-X3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2000
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Package / Case SC-20, Stud
Mounting Type Stud Mount
Mount Stud
Supply Chain
Factory Lead Time 6 Weeks
