C180DX500
RoHS
RoHS compliant
RoHS compliantPackage TO-209AB, TO-93-4, Stud
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
THYRISTOR STUD 400V 190A TO-93
PDF
/
Inventory: 4473
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Chassis, Stud
Mounting Type Chassis, Stud Mount
Package / Case TO-209AB, TO-93-4, Stud
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Published 2000
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
HTS Code 8541.30.00.80
Subcategory Silicon Controlled Rectifiers
Terminal Position UPPER
Terminal Form HIGH CURRENT CABLE
Reach Compliance Code unknown
JESD-30 Code O-CEDB-X3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
RMS Current (Irms) 300A
Trigger Device Type SCR
Voltage - Off State 400V
Voltage - Gate Trigger (Vgt) (Max) 3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 5000A 5500A
Current - Gate Trigger (Igt) (Max) 150mA
Repetitive Peak Off-state Voltage 400V
Leakage Current (Max) 10mA
Current - On State (It (AV)) (Max) 190A
Non-Repetitive Pk On-state Cur 5500 A
SCR Type Standard Recovery
Voltage - On State (Vtm) (Max) 2.85V
Critical Rate of Rise of Off-State Voltage-Min 200V/us
Current - Off State (Max) 20mA
Repetitive Peak Reverse Voltage 400V
Holding Current-Max 500mA
Compliance
RoHS Status RoHS Compliant
