VS-VSKV56/14
RoHS
RoHS compliant
RoHS compliantPackage ADD-A-PAK (3 + 4)
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Bulk Common Cathode - All SCRs Chassis Mount 2SCRs SCR Module 1200A 1256A 150mA 2.5V -40C~125C TJ
PDF
/
Inventory: 1438
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case ADD-A-PAK (3 + 4)
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2016
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
RMS Current (Irms) 95A
Hold Current 200mA
Voltage - Off State 1.4kV
Voltage - Gate Trigger (Vgt) (Max) 2.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 1200A 1256A
Current - Gate Trigger (Igt) (Max) 150mA
Current - Hold (Ih) (Max) 200mA
Current - On State (It (RMS)) (Max) 95A
Structure Common Cathode - All SCRs
Current - On State (It (AV)) (Max) 60A
Number of SCRs, Diodes 2 SCRs
Compliance
RoHS Status ROHS3 Compliant
