VS-VSKL41/08
RoHS
RoHS compliant
RoHS compliantPackage ADD-A-PAK (3 + 4)
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Bulk Series Connection - SCR/Diode Chassis Mount Diodes SCR Module 850A 890A 150mA 800V -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $80.86
Unit Price: USD $80.858885
≥1 USD $80.858885
≥200 USD $32.263205
≥500 USD $31.185314
≥1000 USD $30.653589
Inventory: 7512
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of SCRs, Diodes 1 SCR, 1 Diode
Structure Series Connection - SCR/Diode
Current - On State (It (RMS)) (Max) 100A
Current - Hold (Ih) (Max) 200mA
Current - Gate Trigger (Igt) (Max) 150mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 850A 890A
Voltage - Gate Trigger (Vgt) (Max) 2.5V
Trigger Device Type SCR
Hold Current 200mA
RMS Current (Irms) 100A
Max Repetitive Reverse Voltage (Vrrm) 800V
Circuit Type Diodes
Current Rating 45A
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 5
Package / Case ADD-A-PAK (3 + 4)
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 14 Weeks
