L613F
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
MODULE SCR/DIO 42.5A 280VAC PCB
PDF
/
Buying Options
Total Price: USD $317
Unit Price: USD $316.998392
≥1 USD $316.998392
≥200 USD $126.484786
≥500 USD $122.258561
≥1000 USD $120.169737
Inventory: 3858
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Module
Number of Pins 6
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2009
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Voltage - Rated DC 800V
Current Rating 42.5A
Output Current 42.5A
Max Repetitive Reverse Voltage (Vrrm) 800V
RMS Current (Irms) 42.5A
Reverse Voltage 280V
Voltage - Off State 800V
Voltage - Gate Trigger (Vgt) (Max) 3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 600A @ 60Hz
Current - Gate Trigger (Igt) (Max) 100mA
Structure Bridge, Single Phase - SCRs/Diodes (Layout 1)
Number of SCRs, Diodes 2 SCRs, 2 Diodes
Dimensions
Height 12.7mm
Length 34.9758mm
Width 28.3972mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
