B522F-2-YEC

Sensata-Crydom
RoHS
RoHS RoHS compliant
Package Module with Isolation Barriers
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description Bulk Bridge Single Phase - SCRs/Diodes (Layout 2) Chassis Mount 2SCRs 2Diodes SCR Module 250A @ 60Hz 60mA 2.5V -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $136.39
Unit Price: USD $136.393242
≥1 USD $136.393242
≥200 USD $54.422331
≥500 USD $52.603964
≥1000 USD $51.704628
Inventory: 1730
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Technical

Number of SCRs, Diodes 2 SCRs, 2 Diodes
Structure Bridge, Single Phase - SCRs/Diodes (Layout 2)
Current - Gate Trigger (Igt) (Max) 60mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 250A @ 60Hz
Voltage - Gate Trigger (Vgt) (Max) 2.5V
Voltage - Off State 600V
RMS Current (Irms) 25A
Current Rating 25A
Part Status Active
Published 2016
Packaging Bulk
Operating Temperature -40°C~125°C TJ

Physical

Package / Case Module with Isolation Barriers
Mounting Type Chassis Mount
Mount Chassis Mount

Supply Chain

Factory Lead Time 6 Weeks
