TD190N16SOFHPSA2
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
THYRISTOR MODULE 1600V 190A
PDF
/
Buying Options
Total Price: USD $44.3
Unit Price: USD $44.2992
≥1 USD $44.2992
≥10 USD $40.275954
≥100 USD $38.9334
≥500 USD $36.248414
≥1000 USD $34.905842
Inventory: 67
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of SCRs, Diodes 2 SCRs
Repetitive Peak Reverse Voltage 1600V
Current - On State (It (AV)) (Max) 190A
Repetitive Peak Off-state Voltage 1600V
Structure Series Connection - All SCRs
Current - On State (It (RMS)) (Max) 275A
Current - Hold (Ih) (Max) 200mA
Current - Gate Trigger (Igt) (Max) 145mA
Voltage - Gate Trigger (Vgt) (Max) 2.5V
Voltage - Off State 1.6kV
Trigger Device Type SCR
Case Connection ISOLATED
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
JESD-30 Code R-XUFM-X5
Reference Standard IEC-747-6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
HTS Code 8541.30.00.80
Additional Feature UL RECOGNIZED
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Bulk
Operating Temperature 125°C TJ
Physical
Surface Mount NO
Package / Case Module
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
