JAN2N2325S
RoHS
/
Package TO-205AA, TO-5-3 Metal Can
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 150V TO205AA
PDF
/
Inventory: 8900
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Current - Off State (Max) 10μA
Voltage - On State (Vtm) (Max) 2.2V
SCR Type Sensitive Gate
Current - On State (It (AV)) (Max) 1.6A
Current - Hold (Ih) (Max) 2mA
Current - Gate Trigger (Igt) (Max) 200μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 15A @ 60Hz
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 150V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Military, MIL-STD-701
Published 1996
Packaging Bulk
Operating Temperature -65°C~125°C
Physical
Package / Case TO-205AA, TO-5-3 Metal Can
Mounting Type Through Hole
