S4015L
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Isolated Tab
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
LITTELFUSE S4015L SCR THYRISTOR, 15A, 400V, TO-220AB
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.60895
≥1 USD $0.60895
≥10 USD $0.4997
≥100 USD $0.48355
≥500 USD $0.46835
≥1000 USD $0.45315
Inventory: 1223
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Current - Off State (Max) 10μA
Critical Rate of Rise of Off-State Voltage-Min 100V/us
Voltage - On State (Vtm) (Max) 1.6V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 150 A
Leakage Current (Max) 1mA
Current - Hold (Ih) (Max) 40mA
Current - Gate Trigger (Igt) (Max) 30mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 188A 225A
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Voltage - Off State 400V
Trigger Device Type SCR
Hold Current 40mA
RMS Current (Irms) 15A
JEDEC-95 Code TO-220AB
Configuration SINGLE
Number of Elements 1
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 10
Current Rating 9.5A
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Voltage - Rated DC 400V
Subcategory Silicon Controlled Rectifiers
Additional Feature UL RECOGNIZED
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code no
JESD-609 Code e3
Published 2004
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Number of Pins 3
Package / Case TO-220-3 Isolated Tab
Mounting Type Through Hole
Mount Through Hole
