EC103D3AP
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
Thyristor SCR 400V 20A 3-Pin TO-92 Ammo
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.722095
≥1 USD $0.722095
≥200 USD $0.288838
≥500 USD $0.278335
≥1000 USD $0.274396
Inventory: 7995
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Technical
Operating Temperature -40°C~110°C
Packaging Tape & Box (TB)
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Subcategory Silicon Controlled Rectifiers
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
RMS Current (Irms) 800mA
Hold Current 8mA
Trigger Device Type SCR
Voltage - Off State 400V
Voltage - Gate Trigger (Vgt) (Max) 800mV
Current - Non Rep. Surge 50, 60Hz (Itsm) 16A 20A
Current - Gate Trigger (Igt) (Max) 500μA
Current - On State (It (RMS)) (Max) 800mA
Repetitive Peak Off-state Voltage 400V
Leakage Current (Max) 0.1mA
Current - On State (It (AV)) (Max) 510mA
Non-Repetitive Pk On-state Cur 20 A
SCR Type Sensitive Gate
Voltage - On State (Vtm) (Max) 1.7V
Critical Rate of Rise of Off-State Voltage-Min 40V/us
Current - Off State (Max) 1μA
Repetitive Peak Reverse Voltage 400V
Compliance
RoHS Status ROHS3 Compliant
