CS19-08HO1
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
IXYS SEMICONDUCTOR CS19-08HO1 THYRISTOR, 19A, 800V
PDF
/
Buying Options
Total Price: USD $2.5
Unit Price: USD $2.502491
≥1 USD $2.502491
≥10 USD $2.21339
≥100 USD $2.032865
≥500 USD $1.847108
≥1000 USD $3.59385
≥3000 USD $3.2224
Inventory: 140
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 2.299997g
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2000
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Subcategory Silicon Controlled Rectifiers
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CS19
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Case Connection ANODE
JEDEC-95 Code TO-220AB
RMS Current (Irms) 29A
Hold Current 50mA
Trigger Device Type SCR
Voltage - Off State 800V
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 160A 180A
Current - Gate Trigger (Igt) (Max) 28mA
Current - On State (It (RMS)) (Max) 29A
Repetitive Peak Off-state Voltage 800V
Leakage Current (Max) 5mA
Current - On State (It (AV)) (Max) 19A
Non-Repetitive Pk On-state Cur 180 A
SCR Type Standard Recovery
Voltage - On State (Vtm) (Max) 1.6V
Critical Rate of Rise of Off-State Voltage-Min 500V/us
Current - Off State (Max) 5mA
Repetitive Peak Reverse Voltage 800V
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
