CEN-U07
RoHS
/
Package TO-202
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bipolar Transistors - BJT NPN Pwr Trans
PDF
/
Inventory: 9406
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 37 Weeks
Physical
Mount Through Hole
Package / Case TO-202
Transistor Element Material SILICON
Technical
Packaging Bulk
Published 2007
JESD-609 Code e0
Pbfree Code no
Part Status Active
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8541.29.00.75
Subcategory Other Transistors
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 1
Polarity NPN
Configuration SINGLE
Power Dissipation-Max 1.75W
Case Connection COLLECTOR
Transistor Application AMPLIFIER
Collector Emitter Voltage (VCEO) 350mV
Max Collector Current 2A
Collector Emitter Breakdown Voltage 100V
Transition Frequency 50MHz
Collector Emitter Saturation Voltage 500mV
Frequency - Transition 50MHz
Collector Base Voltage (VCBO) 100V
Emitter Base Voltage (VEBO) 4V
hFE Min 20
DC Current Gain-Min (hFE) 20
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
