CF25-103-JTW
RoHS
/
Package Axial
Category Resistors / Through Hole Resistors
Description
FIXED RESISTOR Axial through hole resistor 5% 10kOhm 250mW
PDF
/
Inventory: 7684
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Axial
Surface Mount NO
Terminal Shape WIRE
Mounting Feature THROUGH HOLE MOUNT
Technical
Packaging Cut Tape
Tolerance 5%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
Resistance 10kOhm
Terminal Finish Matte Tin (Sn)
Subcategory Fixed Resistors
Power Rating 250mW
Packing Method TR
Technology CARBON FILM
Construction Cylindrical
Resistor Type FIXED RESISTOR
Reference Standard MIL-R-11
Rated Power Dissipation (P) 0.25W
Operating Temperature (Max) 155°C
Operating Temperature (Min) -55°C
Working Voltage 250V
Lead Diameter 0.6 mm
Rated Temperature 70°C
Compliance
RoHS Status RoHS Compliant
Alternative Model
