2-320559-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Wire Splice Connectors
Description
CONN SPLICE 16-22 AWG CRIMP PIDG
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.9504
≥1 USD $0.9504
≥10 USD $0.89144
≥100 USD $0.857824
≥500 USD $0.849728
≥1000 USD $0.766832
≥3000 USD $0.741946
Inventory: 1169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Physical
Insulation Material Nylon
Body Material Copper
Technical
Packaging Tape & Reel (TR)
Published 2006
Series PIDG
Feature Serrated Mating Area
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Wire Gauge 16-22 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 16 AWG
Body Plating Tin
Sealable No
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Diameter 3.18 mm
Insulation Fully Insulated
Terminal Type Butt Splice, Inline, Individual Openings
Number of Wire Entries 2
Government Qualified Yes
Dimensions
Length 32.13mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
