10002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Wire Splice Connectors
Description
Terminals Copper Standard Barrel Connector
PDF
/
Buying Options
Total Price: USD $115.39
Unit Price: USD $115.3856
≥1 USD $115.3856
≥10 USD $104.896
Inventory: 91
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 30μin
Length 44.5mm
Technical
Number of Wire Entries 2
Contact Design PREASSEM CONN
Terminal Type Butt Splice, Inline, Individual Openings
Insulation Non-Insulated
Contact Pattern RECTANGULAR
Wire/Cable Gauge 4 AWG
Dielectric Withstanding Voltage 1000VAC V
Mating Contact Pitch 0.1 inch
Wire Gauge 4 AWG
Contact Style BLADE PIN-SKT
Rated Current (Signal) 1A
Body Depth 0.709 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender FEMALE
Body Breadth 0.441 inch
Operating Temperature (Max) 105°C
Reliability COMMERCIAL
Reference Standard UL
Total Number of Contacts 20
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD (30) OVER NICKEL (100)
Subcategory Headers and Edge Type Connectors
Additional Feature PANEL MOUNTABLE
Voltage - Rated 35kV
Number of Rows 2
Color Gray
Connector Type CARD EDGE CONNECTOR
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Copper Wire Only
Series Scotchlok?
Published 2014
Packaging Bulk
Physical
Mounting Style RIGHT ANGLE
Insulation Material GLASS FILLED POLYESTER
Mounting Type BOARD
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 3 Weeks
