1514-2 image
Favorite
1514-2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Turret Connectors
Description KEYSTONE 1514-2 TERMINAL, TURRET, 0.09IN, THROUGH HOLE
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.4752
≥1 USD $0.4752
≥10 USD $0.398112
≥100 USD $0.346016
≥500 USD $0.321235
≥1000 USD $0.294906
≥3000 USD $0.243294
Inventory: 1313
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Diameter - Turret Head 0.109 (2.77mm)
Length - Above Board 0.281 7.14mm
Length - Below Flange 0.105 2.67mm
Board Thickness 0.062 1.57mm
Diameter - Inside 2.29 mm
Length - Overall 0.386 9.80mm
Length 10mm
Diameter 2.29mm

Technical

Staking Side OD 0.090 (2.29mm)
Number of Turrets Double
Flange Diameter 0.156 (3.96mm)
Hole Diameter 2.3876 mm
Terminal Type Single End
Insulation Non-Insulated
Terminal and Terminal Block Type PCB TERMINAL
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Staking Flare
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2008

Physical

Mounting Hole Diameter 0.094 (2.39mm)
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass

Supply Chain

Factory Lead Time 6 Weeks
